Tools and accessories
Specialized tools and accessories designed for safe handling and maintenance in the railway industry.
We offer complete tooling solutions – from manual crimping tools, through hydraulic and electro-hydraulic crimping systems for terminals and connectors, to accessories that support process control and repeatability.
Even faster and more repeatable crimping
The ET300 is a compact, automated electro-hydraulic tool for crimping terminals onto wires, designed for intensive and precise work.
Automating the process significantly reduces the crimping time while ensuring consistent quality for every connection.. One tool replaces a full set of hand tools, offering convenience, versatility, and consistent results.
The ET300 is ideal for serial production – it allows for up to 100,000 crimps per year while maintaining full control over process parameters. Compatibility with specialized SICAME terminals guarantees high quality and durability of connections.
Up to
100 000
crimps
per year
Automated wire terminal crimping, designed for faster and more precise operation.
Matryce do narzędzia
Przyrząd kontrolny Go/no-go
Select the appropriate tool:
Manual crimping tool for pre-insulated terminals (1–2.5 mm²)
TH 1 / TH1s
Designed for crimping red pre-insulated terminals, disconnects, pins, spade connectors, and butt splices within the range of 0.34–1.5 mm².
Aluminum body
Exceptionally low gear ratio (reduced force required)
High quality clamping thanks to the linear movement of the dies
Adjustable wire insulation clamp with eccentric mechanism
Ratchet mechanism enhancing operational safety
Positioning Stop
Crimping die marking: 1 line
Length: 290 mm
Weight: 0.500 kg
TH 1: Supplied with the HD20 locator for terminals, disconnects, and pins.
TH1S: Supplied with the HD20 locator for terminals, disconnects, pins, and tubular lugs.
Manual crimping tool for pre-insulated terminals (1–2.5 mm²)
TH 2
Designed for crimping blue pre-insulated terminals, disconnects, pins, spade connectors, and tubular lugs within the range of 1.0–2.5 mm².
Aluminum body
Minimal use of force
High quality clamping thanks to the linear movement of the dies
Adjustable wire insulation clamp with eccentric mechanism
Ratchet mechanism enhancing operational safety
Positioning Stop
Crimping die marking: 2 lines
Length: 290 mm
Weight: 0.500 kg
TH 2: Supplied with the HF20 locator for terminals, disconnects, pins, and flat connectors.
TH2 S: Supplied with the HF20 locator for terminals, disconnects, pins, and tubular connectors.
Electro-hydraulic crimping tool (10–70 mm²)
TH 3 / TH3-2
Designed for crimping blue pre-insulated terminals, disconnects, pins, spade connectors, and tubular lugs within the range of 1.0–2.5 mm².
Aluminum body
Minimal use of force
High quality clamping thanks to the linear movement of the dies
Adjustable wire insulation clamp with eccentric mechanism
Ratchet mechanism enhancing operational safety
Positioning Stop
Crimping die marking: 2 lines
Length: 290 mm
Weight: 0.500 kg
Electro-hydraulic crimping tool (10–70 mm²)
EID51
Designed for crimping blue pre-insulated terminals, disconnects, pins, spade connectors, and butt splices within the range of 1.0–2.5 mm².
Aluminum body
Minimal use of force
High quality clamping thanks to the linear movement of the dies
Adjustable wire insulation clamp with eccentric mechanism
Ratchet mechanism enhancing operational safety
Positioning Stop
Crimping die marking: 2 lines
Length: 290 mm
Weight: 0.500 kg
Electro-hydraulic press
ESD50
Pressing force: 50 kN
Stroke: 13 mm
Capacity: 200 to 500 crimps per 5.0 Ah battery
Cycle time: 2–4, depending on the cross-section.
Dimensions: 350 x 310 x 72 mm
Weight: 4.0 kg (with battery)
New Features:
Electronic Cycle Control
Piston return programming based on user preference (automatic or manual)
Automatic or manual return
Automatic shut-off after cycle completion
Two-stage hydraulic pump with a control valve, increasing efficiency by 20–40%.
Return Audio Signal
New PC Software for Diagnostics and Data Analysis
Repeatable and controlled clamping
Each of the tools has been designed to ensure repeatable, controlled crimping using B-crimping technology. The catalog includes, among others:
- tools for pre-insulated products,
- Electro-hydraulic tools for terminals,
- crimping tools for copper tubular lugs and butt connectors,
- pumps, hydraulic kits and cycle counters,
- cable cutting and processing tools,
- Breakdown of the number of crimps by tool type.
Each of them was designed with repeatable, controlled crimping using B-type crimping technology.
