Terminals for PROTECT surge arresters.
PROTECT clamp series
We are the only ones on the market offering a complete set: a stopper plus a dedicated PROTECT clamp.
You gain compatibility, a certified product, and time savings.
Application:
They are used to make electrical connections between insulated conductors of main lines and branch lines with aluminum (Al) or copper (Cu) conductors, as well as to connect aluminum and copper conductors and cables.
| A | Straight line clamp for bare wires 16-120 mm² |
| B | T1 PROTECT Insulation-piercing connector for insulated Al/Cu conductors 16–120 mm² |
| C | TTD1 PROTECT Double-sided insulation-piercing connector: main line Al/Cu 16–120 mm², insulated tap Al/Cu 16–95 mm² |
| D | NTD 1 Protect Single-sided insulation-piercing connector: main line bare Al 16–120 mm, tap line insulated Al/Cu 16–95 mm² |
| E | TND1 PROTECT Single-sided insulation-piercing connector: insulated main line (Al/Cu) 16–120 mm²; bare tap line (Al) 16–120 mm² |
| F | F-type terminal - 16mm² insulated wire - 230mm (pipe). Compatible with insulation-piercing terminals. |
| G | G-type clamp – a clamp for the direct connection of the surge arrester to the transformer. |
| H | H-type clamp – a clamp for the direct connection of a surge arrester to a TOGA-type terminal. |
| I | Type P conductor – flexible copper cable with a 10 mm² cross-section and insulation, 700 mm in length, featuring an Ø 8 mm ring terminal for connection to the earthing terminal. |
Compliant with standards: PN-EN 50483-1 and PN-EN 50483-4.
Clamps
To download:
Limiter series PROTECT
Designed to protect devices in low-voltage power networks against direct and indirect atmospheric overvoltages, as well as switching overvoltages.
